Robot vacuum map overlaps rooms: what should you check before a reset?
Do not delete the map immediately. If the wall outline is correct and only room names or divisions are wrong, start with room editing. Overlapping walls, rotated geometry or a robot shown beyond a wall call for checks of localisation and the correct floor map.
- Record the current setup: capture the map, no-go zones, room names and schedules. A screenshot is not a restorable map backup.
- Check the floor and dock: select the correct saved map and check dock position and approach space against your model’s manual. Avoid repeatedly moving the dock within the same trial.
- Make the smallest relevant change: edit room boundaries, select the right map, or restore a known-good version if the model provides that function.
- Remap only when the geometry remains wrong. Before restarting schedules, check boundaries, exclusions and the return route. Report recurring errors to support with the model, app version and trial details.
Buttons and backup features differ by model. The symptom table below separates the possible problems; the manufacturer sources farther down do not form one universal procedure for every robot.
Does it happen after carrying the robot upstairs? Check multi-floor operation
On this page
Different problems can look like a bad map
| Symptom | Possible problem | Scope of correction |
|---|---|---|
| Correct outline, wrong kitchen/living-room split | Room boundaries | Edit the division in the app |
| The wrong floor is selected | Active map or floor recognition | Check the intended saved map |
| Double walls or rotated rooms | Mapping or localisation error | Dock, operating conditions and a valid saved version if available |
| Correct physical position but an old app display | Delayed information | Check connectivity and reopen the map |
Roborock documents room editing, multi-floor maps and incorrect map angles separately. These functions are not interchangeable. Older support instructions refer to specific models and app layouts; check the current device documentation before following a sequence of buttons.
Preserve the settings before changing them
Capture the current map, schedules, no-go zones and room names. Record when the problem started: after moving the dock, making a new map, changing floors or without an obvious trigger. If the app offers saved map versions or a backup, identify a known-good date before choosing restoration.
A screenshot records settings but cannot itself restore a map. After deleting a map, do not assume that exclusions and room tasks will return automatically. This matters especially where boundaries protect areas the machine should not enter.
Check the reference point: the dock
Roborock’s map-angle support article includes dock placement among the checks. Use the clearances in your own dock’s manual: a large washing station may have different requirements from a compact charging base. Check that the dock is stable, has not moved during cleaning and has the required approach space.
Do not reposition it repeatedly within the same trial. Clean accessible navigation components as directed and remove temporary obstructions that prevent docking. If the displayed map belongs to another level, select the correct saved map using the model’s multi-floor procedure first.
Choose the smallest relevant correction
| Step | When it fits | Check afterwards |
|---|---|---|
| Edit room divisions | The outline is correct | Names, room tasks and boundaries |
| Select the right map | Another floor is active | Robot position and that floor’s exclusions |
| Restore a saved version | A recognised good copy is available | Whether exclusions and schedules are current |
| Map again | Geometry remains wrong | Full outline, return route and recreated restrictions |
| Contact support | The error returns under correct conditions | Logs and model-specific instructions |
Accept the new map before resuming schedules
If remapping is necessary, create ordinary working conditions with access to the intended rooms and a stable dock. Follow the model’s mapping procedure. After saving, inspect boundaries, excluded areas and room assignments before resuming unattended schedules.
Run a short task to a selected room and check the return. A plausible drawing alone does not prove that the robot recognises its position and route. If the geometry becomes distorted again, a report containing before-and-after captures is more useful than another reset that discards the evidence.
Your next step
Capture the current map, choose the smallest necessary correction and verify a one-room task. In a multi-floor home, check the active floor map too.
Sources and method
Documentation checked on 12 September 2026. Model information comes from manufacturer materials. Acceptance sheets, comparison procedures and worked examples are RoboMorrow editorial analysis, not results of our hands-on device tests. Confirm requirements for the exact variant and market.
